Monroe/Trek Model 282H Static Locator


200kV/foot Range
Digital Stat-Arc 2 Static Locator, Modulated

Model 282H Digital Stat-Arc 3 Static Locator

With the Model 282H, accuracy is unquestioned.  Just hold the instrument so the LED beams converge.  That means you are exactly the right distance from the target for readings up to 200kV.  And the chopper-stabilized circuitry is immune to ionization.  Zeroing is push-button simple.  Low cost is designed in too.  You cannot afford not to keep the Model 282H handy for:

*Measuring — static buildup on webs in converting, laminating, and printing operations

*Checking — grounds and bonding in dry particle / powder transport systems

Accuracy has never come so easily or inexpensively. Converging  beams from two LEDs tell you when the instrument is precisely 1 foot from the  target, so reading is an exact indication of the static field being measured, up  to ±200 kV. Lesser ranges of up to ±20 kV can be measured by decreasing the  distance to the target by given amounts and dividing the displayed reading by  4. The Model 282H also features a HOLD button to freeze display and  automatic polarity detection. The chopper-stabilized design guarantees accurate  readings even in ionized environments.

Feature 1: Patented Auto-Zero Circuit
Feature 2: Pulsing-Beam Range Finder for Correct Readings  Always

Size 2.4 x 4.2 x 0.9 inches (6.1 x 10.7 x 2.3 cm)
Weight 5 oz (0.14kg) with battery
Power Requirements 9 volt, Eveready #216 or equivalent NEDA #1604
Meter Range 0 to ± 199.9kV at one foot. For other ranges see “Additional  Information”
Display Type: LCD
Output: 1 volt signal represents 10kV reading
Accuracy ± 5% of reading
Additional Information: Ranges:

kV——-Distance—–Divide Reading by

0-20—–1.0  inches——-4

Model 282H Digital Stat Arc 3  Products

Description Part Number Unit Price Internet Price
Model 282H Digital Stat-Arc 3 Static Locator MMF0282H $ 1457.00 $ 1457.00 ORDER NOW

(**Monroe/Trek products do not qualify for flat rate shipping!)
